Name: Drain Structure

Display Field: HUNAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This dataset contains storm drain structures used for Public Works GIS/SAP Work Management System. The layer is created and maintained to ensure that infrastructure is represented in the appropriate spatial context with sufficient attribution to determine structural material, sizes, and configurations.

Service Item Id: 3379be4d42e04ed8ae0755a01005006f

Copyright Text: City of San Diego, Stormwater Department

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 350000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6240827.056280047
YMin: 1777337.020770058
XMax: 6352868.861395463
YMax: 1986073.2358427346
Spatial Reference: 102646  (2230)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: CODE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: C
  Label: Cap
  Description: N/A
  Symbol:

• Value: M
  Label: Cleanout
  Description: N/A
  Symbol:

• Value: L
  Label: Connector
  Description: N/A
  Symbol:

• Value: N
  Label: Debris Fence
  Description: N/A
  Symbol:

• Value: S
  Label: Desilting Basin
  Description: N/A
  Symbol:

• Value: D
  Label: Drop Manhole (Inlet)
  Description: N/A
  Symbol:

• Value: E
  Label: Energy Dissipator
  Description: N/A
  Symbol:

• Value: H
  Label: Headwall
  Description: N/A
  Symbol:

• Value: I
  Label: Inlet
  Description: N/A
  Symbol:

• Value: G
  Label: Low Flow Diversion
  Description: N/A
  Symbol:

• Value: O
  Label: Outlet
  Description: N/A
  Symbol:

• Value: F
  Label: Sewer Connector
  Description: N/A
  Symbol:

• Value: A
  Label: Spillway
  Description: N/A
  Symbol:

• Value: T
  Label: Tide Gate
  Description: N/A
  Symbol:

• Value: W
  Label: Weep Sump
  Description: N/A
  Symbol:

• Value: X
  Label: Unknown
  Description: N/A
  Symbol:

• Value: P
  Label: SUMP PUMP
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• IAMFLOC ( type: esriFieldTypeString, alias: IAMFLOC, length: 30 )
• SAPOBJNR ( type: esriFieldTypeString, alias: SAPOBJNR, length: 22 )
• CODE ( type: esriFieldTypeString, alias: Structure Type, length: 1 )
• STATUS ( type: esriFieldTypeString, alias: Active Status, length: 1 )
• MAPNG_STAT_CD ( type: esriFieldTypeString, alias: Mapping Status, length: 2 )
• ELEVATION ( type: esriFieldTypeDouble, alias: Ground Surface Elevation )
• LOC_DESC ( type: esriFieldTypeString, alias: Location Description, length: 40 )
• DRAWING_NO ( type: esriFieldTypeString, alias: As-Built Drawing Number, length: 30 )
• INSTALL_YE ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• INST_YR ( type: esriFieldTypeDate, alias: Install Date Year, length: 8 )
• ASBUILT_DATE ( type: esriFieldTypeDate, alias: As-Built Date, length: 8 )
• ASM_INST_D ( type: esriFieldTypeString, alias: Assumed Install Date, length: 50 )
• SUBDIV_DWG ( type: esriFieldTypeString, alias: Subdivision Map Number, length: 30 )
• EASEMENT_DWG ( type: esriFieldTypeString, alias: Easement Drawing Number, length: 30 )
• EASEMENT ( type: esriFieldTypeString, alias: Easement Description, length: 100 )
• ERA ( type: esriFieldTypeString, alias: Encroachment Removal Agreement (ERA), length: 25 )
• WORK_ORDER ( type: esriFieldTypeString, alias: Project Number, length: 10 )
• WATERSHED ( type: esriFieldTypeSmallInteger, alias: Watershed )
• MWMP_WATERSHED ( type: esriFieldTypeSmallInteger, alias: MWMP Watershed )
• HU ( type: esriFieldTypeInteger, alias: Hydrologic Unit )
• HA ( type: esriFieldTypeInteger, alias: Hydrologic Area )
• HSA ( type: esriFieldTypeInteger, alias: Hydrologic Sub Area )
• HUNAME ( type: esriFieldTypeString, alias: Hydrologic Unit Code, length: 35 )
• HANAME ( type: esriFieldTypeString, alias: Hydrologic Area Code, length: 35 )
• HSANAME ( type: esriFieldTypeString, alias: Hydrologic Sub Area Code, length: 35 )
• CDCODE ( type: esriFieldTypeSmallInteger, alias: Council District )
• CPCODE ( type: esriFieldTypeSmallInteger, alias: Community Planning Area )
• STENCILED ( type: esriFieldTypeString, alias: Stenciled, length: 10 )
• STENCIL_TYPE ( type: esriFieldTypeString, alias: Stencil Type, length: 30 )
• LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
